Double rubber nipper roller is used for paper feeding, whose pressure can be adjusted by pneumatic component;taper tension control system ensures the printing accuracy.
Double rubber nipper roller is used for paper feeding, whose pressure can be adjusted by pneumatic component;taper tension control system ensures the printing accuracy.
Ceramic anilox roller for ink transferring ;Single -blade reverse ink-scraping sstem; pneumatic clutch pressure for anilox rollers and plate rollers. Automaitc preverting clogging function:when te machine stops, the anilox roller wll rotate to prevent the ink on its surface from drying and blocking holes(meshes)on it.
|
Type |
KDZJ-1050A |
KDZJ-1350A |
KDZJ-1550A |
|
Max. Web Width |
1050mm |
1350mm |
1550mm |
|
Max. printing width |
1000mm |
1300mm |
1500mm |
|
Printing repeat |
380-1200mm |
380-1600mm |
380-1600mm |
|
Max. unwinder diameter |
1524mm |
1524mm |
1524mm |
|
Max. rewinder diameter |
1524mm |
1524mm |
1524mm |
|
Gearing |
1/8cp |
1/8cp |
1/8cp |
|
Max. printing speed |
150m/min |
150m/min |
150m/min |
|
Diameter of web roller |
100mm |
100mm |
100mm |
|
Motor power |
11kw~15kw |
15kw~18.5kw |
18kw-22kw |
|
Oil used |
A.Aqueous ink B. UV ink |
||
|
Drying mode |
A.Warm Drying B.IR Drying C.UV Drying |
||
|
Power requirement |
380V 3PH 50HZ |
380V 3PH 50HZ |
380V 3PH 50HZ |
